Project

Parameter

Machine Name

RNC-300-2

Processing range

Steel cylindrical ф180 ~ ф300

Power head count

Two power head

Processing Material

Cast  steel

Capacity

90~180s/pcs

Spindle speed

40~400rpm  Six gear transmission

Spindle travel

Zaxle

≤90mm

Xaxle

≤300mm

Control Systems

CNC system

Fixture Type

Hydraulic or manual

Spindle drive

Stepper motor

Spindle motor drive

Contacts

Spindle motor power

3kw/6p×2

Power supply

Three-phase  AC380v/50HZ

Total power

9kw

Dimensions

3200mm×1350mm×1900mm

Weight

3800kg
